| Condensing temperature output | +4℃±0.2℃ (factory setting |
| Sampler gas dew point output | ≤5.0℃ at 25℃ with gas flow 2NL/min |
| Working temperature | +2℃ to +45℃ |
| Sampling gas dealing ability | 250NL/h |
| Sampler gas dew point output (Max) | ≤+80℃ |
| Sampler gas temperature | ≤+180℃ |
| Sampler gas pressure | ≤3bar |
| Different pressure | ≤3mbar |
| Inlet connector | OD6mm |
| Outlet connector | OD6mm |
| High temperature alarming | ≥+8℃ alarming |
| Low temperature alarming | ≤+2℃ alarming |
| Warm up | ≤30min |
| Power supply | 220V AC 50Hz |
| Power consumption | 150W |
| Dimension | 240W*215H*180Dmm |
| Weight | 7kg |
EC122 semiconductor condenser is widely used inrapid dehydration and minimizes water-soluble components of gas lost, for online gas analysis instruments, providing a complete sample drying gas. It can work in ambient temperature of +2℃ to +45 ℃.
| Condensing temperature output | +4℃±0.2℃ (factory setting |
| Sampler gas dew point output | ≤5.0℃ at 25℃ with gas flow 2NL/min |
| Working temperature | +2℃ to +45℃ |
| Sampling gas dealing ability | 250NL/h |
| Sampler gas dew point output (Max) | ≤+80℃ |
| Sampler gas temperature | ≤+180℃ |
| Sampler gas pressure | ≤3bar |
| Different pressure | ≤3mbar |
| Inlet connector | OD6mm |
| Outlet connector | OD6mm |
| High temperature alarming | ≥+8℃ alarming |
| Low temperature alarming | ≤+2℃ alarming |
| Warm up | ≤30min |
| Power supply | 220V AC 50Hz |
| Power consumption | 150W |
| Dimension | 240W*215H*180Dmm |
| Weight | 7kg |
