Introduction

The ESEGAS VOC Analyzer is designed for continuous measurement of volatile organic compounds (VOCs) in industrial exhaust gases and emission streams. Based on Flame Ionization Detection (FID), it measures hydrocarbon compounds by detecting the ions generated when organic molecules pass through a hydrogen flame. Depending on the configured measurement method, it can analyze total hydrocarbons (THC), methane, non-methane hydrocarbons (NMHC), and selected VOC groups such as benzene-series compounds. The analyzer provides continuous emission data for petrochemical plants, chemical manufacturing facilities, industrial coating processes, and VOC emission control systems.

Measured Gas: Total hydrocarbons | Methane | Nonmethane hydrocarbons | Benzene series | other volatile organic compounds

Technology: FID

Applications:  Petrochemical processes, chemical manufacturing, industrial exhaust and emission control systems.

Measuring Principle

1) The Hydrogen FID (Flame lonization Director) in VOC analyzer
When volatile organic compound (VOC) burn in a hydrogen flame, high temperatures ionize the gas molecules. This process releases free electrons, which an electric field gradient efficiently directs toward a electrode collector. As electrons accumulate, they generate a measurable ionization current. Since the current strength directly correlates with VOC concentration, analysts use this linear relationship to quantify trace gas components in environmental monitoring and industrial safety applications.
FID-detection-principle
FID-detection-principle
  2) Chromatographic Column Separation Process in VOC analyzer Chromatographic column Chromatographic-column 1
The carrier gas propels the sample mixture toward the chromatographic column’s right end. As the multicomponent gas flows through the column, the stationary phase selectively adsorbs its molecules. Since each gas component interacts uniquely with the stationary phase, their migration rates diverge significantly. This retention time variation enables precise component separation at the column outlet.

Technical Specification

Measurement principle Gas Chromatography Principle (GC-FID)
Detector Flame ionization detector (FID)
Measured components VOCs (total hydrocarbons, Methane, Nonmethane hydrocarbons, Benzene series and other volatile organic compounds)
Measuring range 0-500ppm (Optional)
Limit of detection Total hydrocarbons: 0.8 mg/m³
Repeatability RSD≤2%
Measurement deviation ≤2%FS
Analysis cycle 120s~180s
Data output RS232/RS485
Rated power 800W, 220VAC/50Hz
Injection mode Sample injection via 14-port valve
Injection volume Sample loop 0.5mL
Chromatographic column 3m PQ, 1.5m PQ, 0.6 mTHC column.
FID temperature 180℃
Valve box heat 50℃~150℃
Column temperature 80℃~120℃
Hydrogen flow rate 45 ml/min
Air flow rate 400 ml/min

Applications

VOC (Volatile Organic Compound) analyzer play a critical role in atmospheric chemistry, acting as key precursors to ozone formation and secondary organic aerosols. Governments now prioritize VOC management, listing them as the fifth major pollutant after COD, ammonia-nitrogen, SO₂, and NOx. Consequently, reducing industrial VOC emissions has become vital for global air quality improvement.
  • Plastic products manufacturing
  • Etroleum refining and petrochemistry
  • Pharmaceutical manufacturing
  • Vehicle surface coating
  • Rubber products manufacturing
  • Printing Industry

VOC Analyzer in Monitoring System Structure

The VOC (Volatile Organic Compound) analyzer integrates into an online monitoring system for precise industrial emissions control. The system has four key subsystems:
  • Gaseous pollutant monitoring subsystem uses a sampling probe with a ceramic filter to extract dust-free gas samples.
  • The flue gas monitoring subsystem employs a TPF-integrated monitor to analyze stacks’ temperature, oxygen, humidity, and flow velocity, while a hygrograph ensures accurate gas moisture measurement.
  • Calibration and assistant subsystem maintain system accuracy through automated checks.
  • Control and data collection subsystem houses a centralized control cabinet with an IPC, heating modules, and a high-temperature pump for real-time data processing.
VOCs Online Monitoring System structure
VOCs Online Monitoring System structure
To enhance reliability, an air compressor provides gas for regular pipeline blowback, minimizing condensation risks in heat-traced sampling lines. This VOC analyzer integrates into an online monitoring system supports VOCs emission reduction and aligns with strict environmental compliance standards.

A VOC analyzer measures volatile organic compounds in industrial exhaust gases and emission streams. It helps facilities monitor hydrocarbon emissions, evaluate pollution control performance, and maintain emission records.

A Flame Ionization Detector (FID) burns the sample gas in a hydrogen flame. Organic compounds generate ions during combustion, and the resulting electrical current is related to the hydrocarbon concentration.

Total hydrocarbons (THC) represent the measured hydrocarbon content, including methane and non-methane hydrocarbons. NMHC represents the hydrocarbon fraction after accounting for methane. The measurement method must be configured appropriately for the required result.

FID can detect many organic compounds but does not independently identify individual compounds. Specific BTX analysis generally requires a separation technique, such as gas chromatography, combined with a suitable detector.

Typical applications include petrochemical production, chemical manufacturing, industrial coating, printing, pharmaceutical production, and exhaust emission monitoring.

Consider whether the application requires THC, methane, NMHC, or individual VOC identification. Other important factors include measurement range, sampling temperature, moisture management, response time, and applicable emission requirements.
